What next? There are probably a few causes that stand out as being the most likely root causes, and now it’s time to take action. You’ve completed a detailed fishbone diagram, and asked why 3 times for each reason. If so, it’s your job to flush this out and solve the root cause of the problem by asking “why, why, why” for each reason. Indeed, these practices may be so ingrained they’re considered part of the job.
Remember that people are natural problem solvers and may have spent years doing creative work arounds, to get over routine problems. Top Tip – and the fish said “What is water?” If you’re team are newly formed, consider using icebreakers or creative brainstorming activities to warm things up. Then as a team, place each reason under the main cause headings, building up a detailed picture of why the problem is happening. Task the team with individually writing problem causes on post-it notes – one problem per note – for, say, 10 minutes. Now it’s over to the team to come up with as many reasons why the problem is occurring. Just make the fishbone fit the problem, and your appetite! There is no right way to do this – indeed you may require 6 bones.
Alternatively, you could list major steps in the process.
In manufacturing, the four main cause headings are usually “Machinery, People, Methods and Material” or in a service industry “Policy, Procedures, Plant and People”. The problem statement is written at the “head” of the fish, with the 4 main causes of the problem coming of from the back bone. In most cases, it will be most practical to write on paper, as this can be rolled up and brought to the next meeting. Remember, you’re aiming to separate fact from opinion and identify the root cause of the problem.ĭraw the following fishbone diagram template up on a flip chart or large board, ensuring plenty of space. If you can’t quantify your problem, consider collecting some data before you go any further. At this point you might reason that it’s better to focus on the larger problem, and attempt to resolve the undercooking problem another day. The problem statement could be refined as “4% of double chocolate chip cookies are burnt, and 0.5% are undercooked, and have to be thrown away”. This might be enough detail, but it’s probably worth detailing “what”, “where”, “when” and “how much” to get a better understanding of the problem. The problem statement could be “Cookies are sometimes burnt or undercooked and have to be thrown away”. Let’s take the fictitious example of a Cookie making process. Okay, you’ve assembled your team – now you have to agree on a problem statement. If your ideal team list is long, your problem is possibly too complex to solve in one hit, so consider breaking your problem up into more manageable (and edible!) chunks.
It’s best to gather a team of people who have the right skills, knowledge and experience of the problem to collectively identify all the reasons why the problem may be occurring. The process to follow is basically the same, regardless of industry or problem. The tool allows a team to identify, explore and display in increasing detail, all of the possible causes of a problem, to eventually flush out the root cause(s) of the problem. If you want to discover the root cause of a problem and need a structured method to guide a team through a problem solving process, then the cause and effect diagram is for you. In this Process Improvement Made Easy series, is the fishbone diagram explained in everyday language. Dr Kaoru Ishikawa, an esteemed quality expert, gave his name to this simple, yet effective problem solving tool. The Ishikawa diagram comes under many guises cause and effect diagram or fishbone diagram, but it’s generally referring to the same problem solving tool.
